Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Current, Primary | 5 A |
| Diameter, Inner | 10.5 mm |
| For Use With | Control relays |
| Function | Current |
| Height | 1.772" (45mm) |
| Length | 2.047" (52mm) |
| Measurement Range | 5 A |
| Output | Relay |
| Series | |
| Standards | UL Listed |
| Technology | Inductive |
| Termination | Cable |
| Type | Inductive |
| Voltage, Switching | 4 Vpk |
| Width | 0.63" (16mm) |
Overview
Thru-Hole: MI5 and MI20 — 0.41"; MI100 and MI500 — 1.06". CE compliant.
