Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Alternate Mfr Part Number | 6027580 |
| Body Style | Cylindrical |
| Connection Type | M12 4-Pin |
| Current Consumption | ≤ 10 mA (without load) |
| Dropout Voltage | ≤ 2 V (at Ia max) |
| Frequency, Switching | 0.2 kHz |
| Housing Material | Stainless Steel, V4A (1.4435, 316L) |
| IP Rating | IP68 ; IP69K |
| Length, Housing | 63.5 mm |
| Measurement Range | 20 mm |
| Mounting Type | M18 Threaded Non-Flush |
| Output | PNP-NO |
| Primary Type | Inductive Proximity Sensors |
| Sensing Range | 0 mm ... 20 mm |
| Series | |
| Shielding | Unshielded |
| Size, Thread | M18 x 1 |
| Special Features | Metal Face, Triple Sensing Range |
| Supply Voltage | 10-30 VDC |
| Thread Length | 35 mm |
| Thread Size | M18 x 1 |
| Type | Inductive |
